EF7 Table Mapping Exception

15/01/2015

Note: This blog post relates to a library undergoing development and as such the information is likely to become outdated.

Even with Database First through the EDMX gone in Entity Framework 7 it's still possible to work with existing databases.

While trying this out with one of my databases I ran into the following Exception:

<Message>An error has occurred.</Message>

<ExceptionMessage>Invalid object name 'SomeClass'.</ExceptionMessage>

<ExceptionType>System.Data.SqlClient.SqlException</ExceptionType>

<StackTrace>
at System.Data.SqlClient.SqlConnection.OnError(SqlException exception, Boolean breakConnection, Action`1 wrapCloseInAction)[...]
</StackTrace>

The Entity Framework "Invalid object name [class name]" exception means that the matching table for one of your classes hasn't been found.

In this case I'm trying to map the SomeClass to the underlying SQL table Map.Test:

[Table("Test", Schema="Map")]
public class SomeClass
{
    public int Id { get; set; }
}

The current version of EF7 (7.0.0-rc1-11953) does not have support for mapping using attributes in this way. Instead one must use Fluent configuration in the DbContext as follows:

public class MyContext : DbContext
{
    public DbSet<SomeClass> SomeClasses { get; set; }

    protected override void OnConfiguring(DbContextOptions options)
    {
        options.UseSqlServer(ConnectionString);
    }

    protected override void OnModelCreating(ModelBuilder modelBuilder)
    {
        base.OnModelCreating(modelBuilder);

        modelBuilder.Entity<SomeClass>().ForRelational().Table(tableName: "Test", schemaName: "Map");
    }
}

The mapping is configured fluently in the OnModelCreating method. For slightly more useful information about setting EF7 up see this link.

I hope this helps!

...

C# Async for Slugs

07/12/2014

Fun fact for you dear reader, I've not been programming for long, my degree was in Chemistry and though I taught myself a little programming during my degree I was mainly focused on Chemistry. This means I've been programming professionally for less time than C# 5 has been released.

This is why I've found tutorials so far for the Async/Await features in C# 5 (Net 4.5) to be a little lacking, they generally assume the reader has been writing async programs prior to the release of the features.

As a solution to this I've endeavoured to write a guide to async for miserable slugs like myself who have not had exposure to async prior to these keywords.

Demo Scenario

We're going to stick with a very simple console app available on GitHub to make sure all the concepts can be understood by a slug.

Our Program.cs main method is shown below:

public static void Main(string[] args)
{
    SlugService slugService = new SlugService();
    slugService.GetSlugs(generation: 1);
}

The GitHub version contains a lot more lines which allow the method calls to be timed with the built in stopwatch.

The Slug Service is tasked with retrieving the records of some slugs we've stored somewhere. Let's see what it does:

...

ASP NET MVC - Model Create With List of Model

25/11/2014

This post runs through how to create a form for creating a model with a list of child models using MVC 5 and Razor.

I've been rather quiet on the blogging front lately, I've been working on getting my MVC 5 quiz application up and running on Azure, it's here if anyone wants to give it a go.

One thing I wanted to do while working on the site was allow for a model to be created along with a list of "sub" models; for example when creating a question it would be nice for a user to also create the answers on the same page.

Setup

To demo this we need a model which could "own" some collection of other items. I happened on the perfect example today in the Json.NET source:

Rabbit with a pancake on its head.

...
